June 22, 2022
Rework for Internal Conductor Mismatch
The team at Circuit Technology Center was tested when a large OEM discovered a design problem with fifty prototype boards. Two pairs of .005" wide traces had their polarity inverted, needing to be crossed, and time was of the essence. Reworking these fully populated, 18-layer boards was made even more difficult because these were internal traces, with one pair on layer 4 and the other on layer 18 ...
Feature Story
BGA Placement Paste or Only Flux
Ask the Experts
What are the risks with using flux-only vs. solder paste for placing BGAs in a hybrid lead-free environment ...
Ask the Experts
Circuit Technology Center Doubles Component-Level Tinning Services Capacity
Circuit Technology Center recently received and commissioned two additional Hentec Odyssey 1325 robotic hot solder dip (RHSD) machines. These new machines double the existing capacity to four machines to meet the increasing demand from the defense and high-reliability customer base that requires component level modification/alteration for tin whisker mitigation, gold mitigation, and lead re-conditioning ...

LEARN MORE
Potted QFP Rework Challenge
A manufacturer of outdoor electronic billboards had hundreds of circuit board assemblies that were returned from the field. They all required removing and replacing a faulty 44-pin fine pitch QFP device. These 15" x 10" circuit ...
Feature Story
Diodes As One Way Regulator Valves
Diodes are found in nearly every electronic device and serve as one-way regulator valves. Diodes allow electricity to flow in only one direction through the device. ...
Technology Briefing
Cartoon
"I found an alternative-fuel vehicle that runs on fat instead of gasoline! Oh wait, it's a bicycle."
Copyright © Randy Glasbergen
Trivia
What does the SWOT stand for in SWOT analysis?
See the answer below.
Quote of the Week
"If your car could travel at the speed of light, would your headlights work?"
Steven Wright
